第58屆Intel ISEF中國參賽項目：離桌式鼠標
成都二十四中學 高三 黃瑞
學科：計算機科學
很多人長時間操作電腦后揉著酸痛的手臂，于是想能否發明一種可以脫離桌面自由移動，又不改變使用習慣的無線鼠標。從而達到即能方便操作現有軟件又能解除使用者的疲勞，擴大使用范圍的目的。
通過觀察機械陀螺儀獲得靈感，經過反復試驗和四代作品改進，利用重力和慣性原理制作了內置萬向節支撐的偏重心球殼體，固定在光電掃描鼠標之下。工作時手腕向需要方向轉動，光電頭與方向固定的球平面產生相對位移，將鼠標對桌平面掃描變?yōu)閷?duì)球面掃描，輸出位移信息，從而實現脫離桌面自由使用。
本離桌式鼠標既可支撐使用亦可懸空使用大大減輕使用疲勞。除用于辦公、教學，娛樂外，特別適合臥床，坐沙發等休閑及特殊場合使用。制作成本低廉，適合推廣。
Free mouse
Computer Sciences
Huang Rui 16，No. 24 Middle School of Chengdu
The purpose of this project is to invent a kind of mouse that can be used freely without the fixed support such as a table, so that it may be applied in more jobs and reduce the users’ fatigue. Its main characters are low cost, acceptable to more people without changing their former habits when using it.
There are two ways in making this kind of mouse. One is to alter the former cursor that scans a fixed plane into one that scans a ball surface which moves together with it. The “universal axis” that is particularly designed supports the aberrant-barycenter ball which is fixed under the cursor. The cursor, via the human hand, will obtain relative displacement away from the ball surface, thus realizes the operation of the mouse. The other way involves aberrant-barycenter wheels, which are stalled vertically, and a mechanical electronic mouse raster axis. The two devices are connected through a rate changeable riving system. With the help of human hand, the relatively stationary wheel drives the raster to operate.
Considering the time, the free mouse designed by above first method operates easy and accurate. It can be used with or without a fixed support. For example, we can use it either dependently e.g. at work, for drawing and games, or independently such as in sofa, bed or for multi-media display. What’s more, the users need no special training in order to manage it freely with no trouble. Therefore, it may greatly reduce the users’ fatigue caused by long time work.
